H_TNFRSF9(4-1BB) Reporter 293 Cell line
Description
Cat. No: GM-C04832
Product: H_TNFRSF9(4-1BB) Reporter 293 Cell line


4-1BB (CD137) is a protein in the TNF receptor superfamily, mainly found on T cells and NK cells. It is crucial for immune responses, enhancing T cell proliferation, survival, and function. Its activation is mediated by the ligand 4-1BBL (CD137L), expressed on activated dendritic cells, B cells, and some tumor cells. The signaling pathway involves TRAF and NF-κB, promoting cell survival and proliferation.

Activation of 4-1BB recruits TRAF2 and TRAF1, activating downstream pathways like NF-κB and MAPK, leading to cytokine production (e.g., IL-2 and IFN-γ). This enhances T cell immune responses, supporting anti-tumor immunity and infection clearance. Thus, 4-1BB is a key target in cancer immunotherapy, with potential as an immune checkpoint inhibitor.

H_TNFRSF9(4-1BB) Reporter 293 Cell line is a clonal stable cell line constructed using lentiviral technology, constitutive expression of the TNFRSF9(4-1BB) gene, along with signal-dependent expression of a luciferase reporter gene. When 4-1BBL binds to 4-1BB, it activates downstream signaling pathways, leading to the expression of luciferase. The luciferase activity measurement indicates the activation level of the signaling pathway and can thus be used to evaluate the in vitro effects of drugs related to TNFRSF9(4-1BB).
Data
Response to Anti-H_TNFRSF9(4-1BB) hIgG4 Antibody (Urelumab). The H_TNFRSF9(4-1BB) Reporter 293 Cell line (Cat. GM-C04832) at a concentration of 1.3E4 cells/well (96-well format) was stimulated with serial dilutions of Anti-H_TNFRSF9(4-1BB) hIgG4 Antibody (Urelumab) (Cat. GM-28954AB) in assay buffer (DMEM + 1% FBS + 1% P.S) for 7 hours. The firefly luciferase activity was measured using the GMOne-Step Luciferase Reporter Gene Assay Kit (Cat. GM-040503). The maximum induction fold was approximately [9.9]. Data are shown by drug mass concentration.
The passage stability of response to Anti-H_TNFRSF9(4-1BB) hIgG4 Antibody(Urelumab). The passage 6, 16 and 26 of H_TNFRSF9(4-1BB) Reporter 293 Cell line (Cat. GM-C04832) at a concentration of 1.3E4 cells/well (96-well format) were stimulated with serial dilutions of Anti-H_TNFRSF9(4-1BB) hIgG4 Antibody(Urelumab) (Cat. GM-28954AB) in assay buffer (DMEM + 1% FBS + 1% P.S) for 7 hours. The firefly luciferase activity was measured using the GMOne-Step Luciferase Reporter Gene Assay Kit (Cat. GM-040503). Data are shown by drug mass concentration.
Specifications
Cat. NoGM-C04832
ProductH_TNFRSF9(4-1BB) Reporter 293 Cell line
Product Format1 vial of frozen cells
Quantity5E6 Cells per vial,1 mL
Storage ConditionsLiquid nitrogen immediately upon receipt
Recovery MediumDMEM+10% FBS+1% P.S
Growth mediumDMEM+10% FBS+1% P.S+4 μg/mL Blasticidin+0.75 μg/mL Puromycin
NoteNone
Freezing Medium90% FBS+10% DMSO
Growth propertiesAdherent
Growth Conditions37°C, 5% CO₂
Safety considerationsBiosafety Level 2
Mycoplasma TestingThe cell line has been screened to confirm the absence of Mycoplasma species.
Materials
ReagentOrdering Information
DMEMGibco/C11995500BT
Fetal Bovine SerumCegrogen biotech/A0500-3010
Pen/StrepThermo/15140-122
BlasticidinGenomeditech/GM-040404
PuromycinGenomeditech/GM-040401
Anti-H_TNFRSF9(4-1BB) hIgG4 Antibody(Urelumab)Genomeditech/GM-28954AB
GMOne-Step Luciferase Reporter Gene Assay KitGenomeditech/GM-040503
Cell Culture

Cell Recovery

Recovery Medium: DMEM+10% FBS+1% P.S

To insure the highest level of viability, thaw the vial and initiate the culture as soon as possible upon receipt. If upon arrival, continued storage of the frozen culture is necessary, it should be stored in liquid nitrogen vapor phase and not at -70°C. Storage at -70°C will result in loss of viability.

a)       Thaw the vial by gentle agitation in a 37°C water bath. To reduce the possibility of contamination, keep the O-ring and cap out of the water. Thawing should be rapid (approximately 2 - 3 minutes).

b)       Remove the vial from the water bath as soon as the contents are thawed, and decontaminate by dipping in or spraying with 70% ethanol. All of the operations from this point on should be carried out under strict aseptic conditions.

c)       Transfer the vial contents to a centrifuge tube containing 5.0 mL complete culture medium and spin at approximately 176 x g for 5 minutes. Discard supernatant.

d)       Resuspend cell pellet with the recommended recovery medium. And dispense into appropriate culture dishes.

e)       Incubate the culture at 37°C in a suitable incubator. A 5% CO₂ in air atmosphere is recommended if using the medium described on this product sheet.

Cell Freezing

Freezing Medium: 90% FBS+10% DMSO

a)          Centrifuge at 176 x g for 3 minutes to collect cells.

b)         Resuspend the cells in pre-cooled freezing medium and adjust the cell density to 5E6 cells/mL.

c)          Aliquot 1 mL into each vial.

d)         Place the vial in a controlled-rate freezing container and store at -80°C for at least 1 day, then transfer to liquid nitrogen as soon as possible.

Cell passage

Growth medium: DMEM+10% FBS+1% P.S+4 μg/mL Blasticidin+0.75 μg/mL Puromycin

For the first 1 to 2 passages post-resuscitation, use the recovery medium. Once the cells have stabilized, switch to a growth medium.

a)          Subculturing is necessary when the cell density reaches 80%. It is recommended to perform subculturing at a ratio of 1:3 to 1:4 every 2-3 days. Ensure that the density does not exceed 80%, as overcrowding can lead to reduced viability due to compression.

b)         Remove and discard culture medium.

c)          Briefly rinse the cell layer with PBS to remove all traces of serum that contains trypsin inhibitor.

d)         Add 1.0 mL of 0.25% (w/v) Trypsin-EDTA solution to dish and observe cells under an inverted microscope until cell layer is dispersed (usually within 30 to 60 seconds at 37°C).

e)          Note: To avoid clumping do not agitate the cells by hitting or shaking the flask while waiting for the cells to detach. Cells that are difficult to detach may be placed at 37°C to facilitate dispersal.

f)          Add 2.0 mL of growth medium to mix well and aspirate cells by gently pipetting.

g)         After centrifugation, resuspend the pellet and add appropriate aliquots of the cell suspension to new culture vessels.

h)         Incubate cultures at 37°C.

Subcultivation Ratio: A subcultivation ratio of 1:3 - 1:4 is recommended

Medium Renewal: Every 2 to 3 days

Notes

a)          Upon initial thawing, a higher number of dead cells is observed, which is a normal phenomenon. Significant improvement is seen after adaptation. Once the cells reach a stable state, the number of dead cells decreases after subculturing and the cell growth rate becomes stable.

b)         Ensure that the cell density does not exceed 80%, as overcrowding may lead to reduced viability due to compression.



Citations

Wenci GONG, Liu Yang, et al. Single-domain 4-1bb antibodies: Patent WO2023061421A1 [P]. 2023-04-20.
