IL-4/IL-13 Reporter 293 Cell Line
Cat. No.
GM-C01511
Size
1 vial
Quote
Description
Data Display
Specifications
Materials
Cell Culture
Related products
Description
Interleukin-4 (IL-4) is a cytokine essential for differentiating Th0 cells into anti-inflammatory Th2 cells. Secreted mainly by Th2 cells, IL-4 promotes B cell proliferation and IgE antibody synthesis, crucial in allergies. IL-4 activates downstream signaling pathways through receptor binding.

Similarly, IL-13 is produced by T cells, including Th2 cells, and shares biological traits with IL-4. Its complex signaling involves receptors like IL-13Rα1, activating downstream pathways.

The IL-4/IL-13 Reporter 293 Cell Line is a clonal stable 293 cell line with signal-dependent expression of a luciferase reporter gene, and it endogenously expresses IL-4Rα and IL-13Rα1. When IL-4/IL-13 binds to the receptor, it activates downstream signaling pathways, leading to the expression of luciferase. Blockade antibodies can block this signal transmission. The measurement of luciferase activity indicates the activation level of the signaling pathway and can thus be used to evaluate the in vitro effects of a neutralizing antibody targeting IL-4 and IL-13.
Interleukin-4 (IL-4) is a cytokine essential for differentiating Th0 cells into anti-inflammatory Th2 cells. Secreted mainly by Th2 cells, IL-4 promotes B cell proliferation and IgE antibody synthesis, crucial in allergies. IL-4 activates downstream signaling pathways through receptor binding.

Similarly, IL-13 is produced by T cells, including Th2 cells, and shares biological traits with IL-4. Its complex signaling involves receptors like IL-13Rα1, activating downstream pathways.

The IL-4/IL-13 Reporter 293 Cell Line is a clonal stable 293 cell line with signal-dependent expression of a luciferase reporter gene, and it endogenously expresses IL-4Rα and IL-13Rα1. When IL-4/IL-13 binds to the receptor, it activates downstream signaling pathways, leading to the expression of luciferase. Blockade antibodies can block this signal transmission. The measurement of luciferase activity indicates the activation level of the signaling pathway and can thus be used to evaluate the in vitro effects of a neutralizing antibody targeting IL-4 and IL-13.
Data Display
Signaling Pathway
Response to Recombinant Human IL-4 Protein. The IL-4/IL-13 Reporter 293 Cell Line (Cat. GM-C01511) at a concentration of 2E4 cells/well (96-well format) was stimulated with serial dilutions of Human IL-4 Protein (R&D SYSTEMS/204-IL/CF) in assay buffer (DMEM+1% FBS+1% P.S) for 7 hours. The firefly luciferase activity was measured using the Luciferase Reporter Assay Kit (Genomeditech). The maximum induction fold was approximately [177.9]. Data are shown by drug mass concentration.
Response to Recombinant Human IL-13 Protein. The IL-4/IL-13 Reporter 293 Cell Line (Cat. GM-C01511) at a concentration of 2E4 cells/well (96-well format) was stimulated with serial dilutions of Human IL-13 Protein (Sino Biological/10369-HNAC) in assay buffer (DMEM+1% FBS+1% P.S) for 7 hours. The firefly luciferase activity was measured using the Luciferase Reporter Assay Kit (Genomeditech). The maximum induction fold was approximately [117.1]. Data are shown by drug mass concentration.
Response to Human IL-4 Protein; His Tag. The IL-4/IL-13 Reporter 293 Cell Line (Cat. GM-C01511) at a concentration of 1.5E4 cells/well (96-well format) was stimulated with serial dilutions of Human IL-4 Protein; His Tag (Cat. GM-88042RP) in assay buffer (DMEM+1% FBS+1% P.S) for 7 hours. The firefly luciferase activity was measured using the Luciferase Reporter Assay Kit (Genomeditech). The maximum induction fold was approximately [173.8]. Data are shown by drug mass concentration.
Applications
Response to Anti-IL-4R hIgG1 Antibody(12B5). Serial dilutions of Anti-IL-4R hIgG1 Antibody(12B5)(Cat. GM-46268AB) were incubated with 2E4 cells/well of the IL-4/IL-13 Reporter 293 Cell Line (Cat. GM-C01511) in a 96-well plate for 1 hour. Then, 0.2 ng/mL of Recombinant Human IL-4 Protein (R&D SYSTEMS/204-IL/CF) was added, and the incubation continued in assay buffer (DMEM + 1% FBS + 1% P.S) for 7 hours. The firefly luciferase activity was measured using the Luciferase Reporter Assay Kit (Genomeditech). The results indicated a maximum blocking fold of approximately [122.2]. Data are shown by drug mass concentration.
Response to Anti-IL-4R hIgG1 Antibody(12B5). Serial dilutions of Anti-IL-4R hIgG1 Antibody(12B5)(Cat. GM-46268AB) were incubated with 2E4 cells/well of the IL-4/IL-13 Reporter 293 Cell Line (Cat. GM-C01511) in a 96-well plate for 1 hour. Then, 3.3 ng/mL of Recombinant Human IL-13 Protein (Sino Biological/10369-HNAC) was added, and the incubation continued in assay buffer (DMEM + 1% FBS + 1% P.S) for 7 hours. The firefly luciferase activity was measured using the Luciferase Reporter Assay Kit (Genomeditech). The results indicated a maximum blocking fold of approximately [130.0]. Data are shown by drug mass concentration.
Response to Human IL-4 Antibody. Begin by preparing the IL-4/IL-13 Reporter 293 Cell Line (Cat. GM-C01511) at a density of 1.5E4 cells/well in a 96-well format. The serial dilutions of Human IL-4 Antibody (R&D SYSTEMS/MAB204) were incubated with 0.2 ng/mL of Recombinant Human IL-4 Protein (R&D SYSTEMS/204-IL/CF) for 1 hour. After pre-incubation, the mixture was added to the IL-4/IL-13 Reporter 293 Cell Line and incubated for 6 hours in assay buffer (DMEM+1% FBS+1% P.S). The firefly luciferase activity was measured using the Luciferase Reporter Assay Kit (Genomeditech). The results indicated a maximum blocking fold of approximately [66.3]. Data are shown by drug mass concentration.
Stability
Response to Recombinant Human IL-4 Protein. The passage 7,17 and 27 of IL-4/IL-13 Reporter 293 Cell Line (Cat. GM-C01511) at a concentration of 1.5E4 cells/well (96-well format) was stimulated with serial dilutions of Human IL-4 Protein (R&D SYSTEMS/204-IL/CF) in assay buffer (DMEM+1% FBS+1% P.S) for 7 hours. The firefly luciferase activity was measured using the Luciferase Reporter Assay Kit (Genomeditech). Data are shown by drug mass concentration.
Response to Recombinant Human IL-13 Protein. The passage 7,17 and 27 of IL-4/IL-13 Reporter 293 Cell Line (Cat. GM-C01511) at a concentration of 1.5E4 cells/well (96-well format) was stimulated with serial dilutions of Human IL-13 Protein (Sino Biological/10369-HNAC) in assay buffer (DMEM+1% FBS+1% P.S) for 7 hours. The firefly luciferase activity was measured using the Luciferase Reporter Assay Kit (Genomeditech). Data are shown by drug mass concentration.
Expression
IL-4/IL-13 Reporter 293 Cell Line was determined by flow cytometry using Anti-IL-4R hIgG1 Antibody(12B5) (Cat. GM-23373AB).
HEK-293 Cell Line was determined by flow cytometry using APC Rabbit anti-Human CD213a1/IL-13Rα1 mAb (ABclonal/A26763).
Specificity
Response to Human IL-13 Protein and Mouse IL-13 Protein. The IL-4/IL-13 Reporter 293 Cell Line (Cat. GM-C01511) at a concentration of 1.5E4 cells/well (96-well format) was stimulated with serial dilutions of Human IL-13 Protein; His Tag (Cat. GM-88040RP) and Mouse IL-13 Protein; His Tag (Cat. GM-88166RP) in assay buffer (DMEM+1% FBS+1% P.S) for 7 hours. The firefly luciferase activity was measured using the Luciferase Reporter Assay Kit (Genomeditech). The maximum induction fold was approximately [192.0] and [147.3]. Data are shown by drug mass concentration.
Response to Cynomolgus IL-13 Protein. The IL-4/IL-13 Reporter 293 Cell Line (Cat. GM-C01511) at a concentration of 1.5E4 cells/well (96-well format) was stimulated with serial dilutions of Cynomolgus IL-13 Protein; His Tag (Cat. GM-88165RP) in assay buffer (DMEM+1% FBS+1% P.S) for 7 hours. The firefly luciferase activity was measured using the Luciferase Reporter Assay Kit (Genomeditech). The maximum induction fold was approximately [126.5]. Data are shown by drug mass concentration.
Specifications
Cat. No GM-C01511
Product IL-4/IL-13 Reporter 293 Cell Line
Product Format 1 vial of frozen cells
Quantity 5E6 Cells per vial,1 mL
Storage Conditions Liquid nitrogen immediately upon receipt
Recovery Medium DMEM+10% FBS+1% P.S
Growth medium DMEM+10% FBS+1% P.S+4 μg/mL Blasticidin+0.75 μg/mL Puromycin
Note None
Freezing Medium 90% FBS+10% DMSO
Growth properties Adherent
Growth Conditions 37°C, 5% CO₂
Safety considerations Biosafety Level 2
Mycoplasma Testing The cell line has been screened to confirm the absence of Mycoplasma species.
Cat. No GM-C01511
Product IL-4/IL-13 Reporter 293 Cell Line
Product Format 1 vial of frozen cells
Quantity 5E6 Cells per vial,1 mL
Storage Conditions Liquid nitrogen immediately upon receipt
Recovery Medium DMEM+10% FBS+1% P.S
Growth medium DMEM+10% FBS+1% P.S+4 μg/mL Blasticidin+0.75 μg/mL Puromycin
Note None
Freezing Medium 90% FBS+10% DMSO
Growth properties Adherent
Growth Conditions 37°C, 5% CO₂
Safety considerations Biosafety Level 2
Mycoplasma Testing The cell line has been screened to confirm the absence of Mycoplasma species.
Materials
Reagent Ordering Information
Puromycin Genomeditech/GM-040401
Blasticidin Genomeditech/GM-040404
Pen/Strep Thermo/15140-122
Fetal Bovine Serum ExCell/FSP500
DMEM Gibco/C11995500BT
Recombinant Human IL-4 Protein R&D SYSTEMS/204-IL/CF
Recombinant Human IL-13 Protein Sino Biological/10369-HNAC
Human IL-4 Antibody R&D SYSTEMS/MAB204
Anti-IL-4R hIgG1 Antibody(12B5) Genomeditech/GM-46268AB
GMOne-Step 2.0 Luciferase Reporter Gene Assay Kit Genomeditech/GM-040513
APC Rabbit anti-Human CD213a1/IL-13Rα1 mAb Abclonal/A26763
Human IL-4 Protein; His Tag Genomeditech/GM-88042RP
Human IL-13 Protein; His Tag Genomeditech/GM-88040RP
Cynomolgus IL-13 Protein; His Tag Genomeditech/GM-88165RP
Mouse IL-13 Protein; His Tag Genomeditech/GM-88166RP
Reagent Ordering Information
Puromycin Genomeditech/GM-040401
Blasticidin Genomeditech/GM-040404
Pen/Strep Thermo/15140-122
Fetal Bovine Serum ExCell/FSP500
DMEM Gibco/C11995500BT
Recombinant Human IL-4 Protein R&D SYSTEMS/204-IL/CF
Recombinant Human IL-13 Protein Sino Biological/10369-HNAC
Human IL-4 Antibody R&D SYSTEMS/MAB204
Anti-IL-4R hIgG1 Antibody(12B5) Genomeditech/GM-46268AB
GMOne-Step 2.0 Luciferase Reporter Gene Assay Kit Genomeditech/GM-040513
APC Rabbit anti-Human CD213a1/IL-13Rα1 mAb Abclonal/A26763
Human IL-4 Protein; His Tag Genomeditech/GM-88042RP
Human IL-13 Protein; His Tag Genomeditech/GM-88040RP
Cynomolgus IL-13 Protein; His Tag Genomeditech/GM-88165RP
Mouse IL-13 Protein; His Tag Genomeditech/GM-88166RP
Cell Culture

Cell Recovery

Recovery Medium: DMEM+10% FBS+1% P.S

To insure the highest level of viability, thaw the vial and initiate the culture as soon as possible upon receipt. If upon arrival, continued storage of the frozen culture is necessary, it should be stored in liquid nitrogen vapor phase and not at -70°C. Storage at -70°C will result in loss of viability.

a)       Thaw the vial by gentle agitation in a 37°C water bath. To reduce the possibility of contamination, keep the O-ring and cap out of the water. Thawing should be rapid (approximately 2 - 3 minutes).

b)       Remove the vial from the water bath as soon as the contents are thawed, and decontaminate by dipping in or spraying with 70% ethanol. All of the operations from this point on should be carried out under strict aseptic conditions.

c)       Transfer the vial contents to a centrifuge tube containing 5.0 mL complete culture medium and spin at approximately 176 x g for 5 minutes. Discard supernatant.

d)       Resuspend cell pellet with the recommended recovery medium. And dispense into appropriate culture dishes.

e)       Incubate the culture at 37°C in a suitable incubator. A 5% CO₂ in air atmosphere is recommended if using the medium described on this product sheet.

Cell Freezing

Freezing Medium: 90% FBS+10% DMSO

a)          Centrifuge at 176 x g for 3 minutes to collect cells.

b)         Resuspend the cells in pre-cooled freezing medium and adjust the cell density to 5E6 cells/mL.

c)          Aliquot 1 mL into each vial.

d)         Place the vial in a controlled-rate freezing container and store at -80°C for at least 1 day, then transfer to liquid nitrogen as soon as possible.

Cell passage

Growth medium: DMEM+10% FBS+1% P.S+4 μg/mL Blasticidin+0.75 μg/mL Puromycin

For the first 1 to 2 passages post-resuscitation, use the recovery medium. Once the cells have stabilized, switch to a growth medium.

a)          Subculturing is necessary when the cell density reaches 80%. It is recommended to perform subculturing at a ratio of 1:3 to 1:4 every 2-3 days. Ensure that the density does not exceed 80%, as overcrowding can lead to reduced viability due to compression.

b)         Remove and discard culture medium.

c)          Briefly rinse the cell layer with PBS to remove all traces of serum that contains trypsin inhibitor.

d)         Add 1.0 mL of 0.25% (w/v) Trypsin-EDTA solution to dish and observe cells under an inverted microscope until cell layer is dispersed (usually within 30 to 60 seconds at 37°C).

e)          Note: To avoid clumping do not agitate the cells by hitting or shaking the flask while waiting for the cells to detach. Cells that are difficult to detach may be placed at 37°C to facilitate dispersal.

f)          Add 2.0 mL of growth medium to mix well and aspirate cells by gently pipetting.

g)         After centrifugation, resuspend the pellet and add appropriate aliquots of the cell suspension to new culture vessels.

h)         Incubate cultures at 37°C.

Subcultivation Ratio: A subcultivation ratio of 1:3 - 1:4 is recommended

Medium Renewal: Every 2 to 3 days

Notes

a)          Upon initial thawing, a higher number of dead cells is observed, which is a normal phenomenon. Significant improvement is seen after adaptation. Once the cells reach a stable state, the number of dead cells decreases after subculturing and the cell growth rate becomes stable.

b)         Ensure that the cell density does not exceed 80%, as overcrowding may lead to reduced viability due to compression.

Cell Recovery

Recovery Medium: DMEM+10% FBS+1% P.S

To insure the highest level of viability, thaw the vial and initiate the culture as soon as possible upon receipt. If upon arrival, continued storage of the frozen culture is necessary, it should be stored in liquid nitrogen vapor phase and not at -70°C. Storage at -70°C will result in loss of viability.

a)       Thaw the vial by gentle agitation in a 37°C water bath. To reduce the possibility of contamination, keep the O-ring and cap out of the water. Thawing should be rapid (approximately 2 - 3 minutes).

b)       Remove the vial from the water bath as soon as the contents are thawed, and decontaminate by dipping in or spraying with 70% ethanol. All of the operations from this point on should be carried out under strict aseptic conditions.

c)       Transfer the vial contents to a centrifuge tube containing 5.0 mL complete culture medium and spin at approximately 176 x g for 5 minutes. Discard supernatant.

d)       Resuspend cell pellet with the recommended recovery medium. And dispense into appropriate culture dishes.

e)       Incubate the culture at 37°C in a suitable incubator. A 5% CO₂ in air atmosphere is recommended if using the medium described on this product sheet.

Cell Freezing

Freezing Medium: 90% FBS+10% DMSO

a)          Centrifuge at 176 x g for 3 minutes to collect cells.

b)         Resuspend the cells in pre-cooled freezing medium and adjust the cell density to 5E6 cells/mL.

c)          Aliquot 1 mL into each vial.

d)         Place the vial in a controlled-rate freezing container and store at -80°C for at least 1 day, then transfer to liquid nitrogen as soon as possible.

Cell passage

Growth medium: DMEM+10% FBS+1% P.S+4 μg/mL Blasticidin+0.75 μg/mL Puromycin

For the first 1 to 2 passages post-resuscitation, use the recovery medium. Once the cells have stabilized, switch to a growth medium.

a)          Subculturing is necessary when the cell density reaches 80%. It is recommended to perform subculturing at a ratio of 1:3 to 1:4 every 2-3 days. Ensure that the density does not exceed 80%, as overcrowding can lead to reduced viability due to compression.

b)         Remove and discard culture medium.

c)          Briefly rinse the cell layer with PBS to remove all traces of serum that contains trypsin inhibitor.

d)         Add 1.0 mL of 0.25% (w/v) Trypsin-EDTA solution to dish and observe cells under an inverted microscope until cell layer is dispersed (usually within 30 to 60 seconds at 37°C).

e)          Note: To avoid clumping do not agitate the cells by hitting or shaking the flask while waiting for the cells to detach. Cells that are difficult to detach may be placed at 37°C to facilitate dispersal.

f)          Add 2.0 mL of growth medium to mix well and aspirate cells by gently pipetting.

g)         After centrifugation, resuspend the pellet and add appropriate aliquots of the cell suspension to new culture vessels.

h)         Incubate cultures at 37°C.

Subcultivation Ratio: A subcultivation ratio of 1:3 - 1:4 is recommended

Medium Renewal: Every 2 to 3 days

Notes

a)          Upon initial thawing, a higher number of dead cells is observed, which is a normal phenomenon. Significant improvement is seen after adaptation. Once the cells reach a stable state, the number of dead cells decreases after subculturing and the cell growth rate becomes stable.

b)         Ensure that the cell density does not exceed 80%, as overcrowding may lead to reduced viability due to compression.
