H_GARP Latent TGFB1 Reporter HEK-293 Cell Line
Description
Cat. No: GM-C13361
Product: H_GARP Latent TGFB1 Reporter HEK-293 Cell Line


GARP (Glycoprotein A Repeat-containing Protein) is a type I transmembrane protein mainly found on regulatory T lymphocytes (Tregs) and platelets. It binds to integrin αVβ6/αVβ8, facilitating the release of active TGF-β, which enhances the suppressive function of Tregs and maintains peripheral tolerance.

In the TGF-β signaling pathway, GARP regulates the retention and activation of latent TGF-β complexes. Latent TGF-β1 associates with Tregs, activated B cells, mesenchymal stromal cells, and platelets via LRRC32 (GARP), allowing it to control latent TGF-β retention. GARP's extracellular region binds to latent TGF-β, while integrin αVβ6/αVβ8 recognizes the RGD sequence in LAP, promoting the release of mature TGF-β.

H_GARP Latent TGFB1 Reporter HEK-293 Cell Line is a clonal stable HEK-293 cell line constructed using lentiviral technology, constitutive expression of the GARP, TGFB1 and TβRI gene, along with signal-dependent expression of a luciferase reporter gene. When αVβ6 binds to GARP, promoting the release of Active TGF-β1, it activates downstream signaling pathways, leading to the expression of luciferase. Blockade antibodies can inhibit this signal transmission. The luciferase activity measurement indicates the activation level of the signaling pathway and can thus be used to evaluate the in vitro effects of drugs related to GARP.
Data
Response to Anti-GARP-TGF-β1 hIgG4 Antibody(ARGX-115). Serial dilutions of the Anti-GARP-TGF-β1 hIgG4 Antibody(ARGX-115) (Cat. GM-30474AB) were incubated with 2E4 cells/well of the H_GARP Latent TGFB1 Reporter HEK-293 (Cat. GM-C13361) in a 96-well plate for 1 hour in assay buffer (DMEM + 1% FBS + 1% P.S). Subsequently, the H_αvβ6 HEK-293 (Cat. GM-C19431) at a concentration of 1E4 cells/well was added, and the co-culture proceeded for an additional 6 hours. Firefly luciferase activity is then measured using the ONE-Glo™ Luciferase Assay System (Promega/E6120). The results indicated a maximum blocking fold of approximately [8.4]. Data are shown by drug mass concentration.
H_GARP Latent TGFB1 Reporter HEK-293 Cell Line (Cat. GM-C13361) was determined by flow cytometry using Anti-GARP-TGF-β1 hIgG4 Antibody(ARGX-115) (Cat. GM-30474AB).
Specifications
Cat. NoGM-C13361
ProductH_GARP Latent TGFB1 Reporter HEK-293 Cell Line
Product Format1 vial of frozen cells
Quantity5E6 Cells per vial,1 mL
Storage ConditionsLiquid nitrogen immediately upon receipt
Recovery MediumDMEM+10% FBS+1% P.S
Growth mediumDMEM+10% FBS+1% P.S+4 μg/mL Blasticidin+150 μg/mL Bleomycin+400 μg/mL G418+125 μg/mL Hygromycin+0.75 μg/mL Puromycin
NoteNone
Freezing Medium90% FBS+10% DMSO
Growth propertiesAdherent
Growth Conditions37°C, 5% CO₂
Safety considerationsBiosafety Level 2
Mycoplasma TestingThe cell line has been screened to confirm the absence of Mycoplasma species.
Materials
ReagentOrdering Information
DMEMGibco/C11995500BT
Fetal Bovine SerumCegrogen biotech/A0500-3010
Pen/StrepThermo/15140-122
BlasticidinGenomeditech/GM-040404
BleomycinGenomeditech/GM-040407
G418Genomeditech/GM-040402
HygromycinGenomeditech/GM-040403
PuromycinGenomeditech/GM-040401
H_αvβ6 HEK-293 Cell LineGenomeditech/GM-C19431
Anti-GARP-TGF-β1 hIgG4 Antibody(ARGX-115)Genomeditech/GM-30474AB
ONE-Glo™ Luciferase Assay SystemPromega/E6120
Cell Culture

Cell Recovery

Recovery Medium: DMEM+10% FBS+1% P.S

To insure the highest level of viability, thaw the vial and initiate the culture as soon as possible upon receipt. If upon arrival, continued storage of the frozen culture is necessary, it should be stored in liquid nitrogen vapor phase and not at -70°C. Storage at -70°C will result in loss of viability.

a)       Thaw the vial by gentle agitation in a 37°C water bath. To reduce the possibility of contamination, keep the O-ring and cap out of the water. Thawing should be rapid (approximately 2 - 3 minutes).

b)       Remove the vial from the water bath as soon as the contents are thawed, and decontaminate by dipping in or spraying with 70% ethanol. All of the operations from this point on should be carried out under strict aseptic conditions.

c)       Transfer the vial contents to a centrifuge tube containing 5.0 mL complete culture medium and spin at approximately 176 x g for 5 minutes. Discard supernatant.

d)       Resuspend cell pellet with the recommended recovery medium. And dispense into appropriate culture dishes.

e)       Incubate the culture at 37°C in a suitable incubator. A 5% CO₂ in air atmosphere is recommended if using the medium described on this product sheet.

Cell Freezing

Freezing Medium: 90% FBS+10% DMSO

a)          Centrifuge at 176 x g for 3 minutes to collect cells.

b)         Resuspend the cells in pre-cooled freezing medium and adjust the cell density to 5E6 cells/mL.

c)          Aliquot 1 mL into each vial.

d)         Place the vial in a controlled-rate freezing container and store at -80°C for at least 1 day, then transfer to liquid nitrogen as soon as possible.

Cell passage

Growth medium: DMEM+10% FBS+1% P.S+4 μg/mL Blasticidin+150 μg/mL Bleomycin+400 μg/mL G418+125 μg/mL Hygromycin+0.75 μg/mL Puromycin

For the first 1 to 2 passages post-resuscitation, use the recovery medium. Once the cells have stabilized, switch to a growth medium.

a)          Subculturing is necessary when the cell density reaches 80%. It is recommended to perform subculturing at a ratio of 1:3 to 1:4 every 2-3 days. Ensure that the density does not exceed 80%, as overcrowding can lead to reduced viability due to compression.

b)         Remove and discard culture medium.

c)          Briefly rinse the cell layer with PBS to remove all traces of serum that contains trypsin inhibitor.

d)         Add 1.0 mL of 0.25% (w/v) Trypsin-EDTA solution to dish and observe cells under an inverted microscope until cell layer is dispersed (usually within 30 to 60 seconds at 37°C).

e)          Note: To avoid clumping do not agitate the cells by hitting or shaking the flask while waiting for the cells to detach. Cells that are difficult to detach may be placed at 37°C to facilitate dispersal.

f)          Add 2.0 mL of growth medium to mix well and aspirate cells by gently pipetting.

g)         After centrifugation, resuspend the pellet and add appropriate aliquots of the cell suspension to new culture vessels.

h)         Incubate cultures at 37°C.

Subcultivation Ratio: A subcultivation ratio of 1:3 - 1:4 is recommended

Medium Renewal: Every 2 to 3 days

Notes

a)          Upon initial thawing, a higher number of dead cells is observed, which is a normal phenomenon. Significant improvement is seen after adaptation. Once the cells reach a stable state, the number of dead cells decreases after subculturing and the cell growth rate becomes stable.

b)         Ensure that the cell density does not exceed 80%, as overcrowding may lead to reduced viability due to compression.
